| Article number: | RMMT-23ALTIC70RD-MD |
| Frame | SMOOTHWALL™ Carbon | Full Sealed Cartridge Bearings | Press Fit BB | Internal Cable Routing | 2-Bolt ISCG05 Tabs | RIDE-9™ Adjustable Geometry | 2 Position Axle | 160mm Travel. SMOOTHWALL™ Carbon Rear Triangle |
| Fork | Fox 38 Float EVOL GRIP2 Performance Elite Series 170mm | 27.5 = 37mm Offset | 29 = 44mm Offset |
| Rear Shock | Fox Float X2 Performance | Sealed Bearing Eyelet | 25x8mm F Hardware | SM = 210x55mm | MD - LG - XL = 230x60mm | Size-Specific tune in FAQ |
| Handlebars | Rocky Mountain AM | 780mm Width | 38mm Rise | 9° Backsweep | 5° Upsweep | 35 Clamp |
| Grips | ODI Elite Pro Lock On |
| Stem | Rocky Mountain 35 AM | 5° Rise | All Sizes = 40m |
| Seatpost | Race Face Turbine R (by Fox) Dropper 30.9mm | SM = 125mm | MD = 150mm | LG = 175mm | XL = 200mm |
| Saddle | WTB Volt Race 142 |
| Shifters | Shimano XT |
| Rear Derailleur | Shimano XT |
| Brakes | Shimano XT Trail 4 Piston | Metal Pads | F:Shimano RT66 203mm | R:Shimano RT66 180mm |
| Cassette | Shimano XT 10-51T |
| Cranks & Chainring | Shimano XT | 32T | 24mm Spindle | 170mm Crank Length |
| Chain | Shimano M8100 |
| Bottom Bracket | Shimano SM-BBMT500 |
| Headset | FSA Orbit NO.57E | Sealed Stainless 36°x45° Bearings | 30.2mm x 41mm x 7.1mm Upper | 40mm x 51.8mm x 7.5mm Lower | 1.5"" Crown Race |
| Front Hub | Rocky Mountain Sealed Boost 15mm |
| Rear Hub | DT Swiss 370 Boost 148mm | 18T Star-Ratchet |
| Spokes | DT Swiss Competition 2.0/1.8/2.0 |
| Tires | F: Maxxis Assegai 2.5 WT 3C MaxxGrip EXO+ Tubeless Ready // R: Maxxis Minion DHR II 2.4 WT 3C MaxxTerra EXO+ Tubeless Ready |
| Rims | Race Face AR 30 | 32H | Tubeless Ready - Tape / Valves Incl |
| Weight NW | This information isn't available yet. We will update the weight of this model as soon as possible. |
