| Article number: | RMMT-22INSA10BL-XL |
"
| Frame Sizes | XS-SM-MD-LG-XL |
| Frame | FORM™ Alloy. Full Sealed Cartridge Bearings. Press Fit BB. Internal Cable Routing. 2-Bolt ISCG05 Tabs. RIDE-9™ Adjustable Geometry. 2 Position Axle. 140mm Travel. FORM™ Alloy Rear Triangle |
| Fork | RockShox Recon Silver RL 150mm | 42mm Offset |
| Handlebar | Rocky Mountain AM | 780mm Width | 25mm Rise | 9° Backsweep | 5° Upsweep | 31.8 Clamp |
| Grips | Rocky Mountain Lock On Light |
| Stem | Rocky Mountain 31.8 AM | 5° Rise | All Sizes = 40m |
| Seatpost | Rocky Mountain Toonie Drop Composite 30.9mm | XS - SM = 125mm | MD = 150mm | LG - XL = 170mm |
| Saddle | WTB Volt 142 |
| Gear Shifters | Shimano Deore 11spd |
| Rear Derailleur | Shimano Deore 11spd |
| Brakes | Tektro HD-M275 | Shimano Pad Compatible | F: Tektro 180mm | R: Tektro 180mm |
| Cassette | SunRace CSMS8 EA1 11-51T |
| Chainwheel & Cranks | Rocky Mountain Microdrive | 32T |Sram 76mm BCD | 24mm Spindle | Crank Length: XS = 165mm | SM - XL = 170mm |
| Chain | KMC X11-1 |
| Bottom Bracket | Rocky Mountain Sealed BB92 - Shimano Compatible |
| Headset | FSA Orbit NO.57E | Sealed 36°x45° Bearings | 30.2mm x 41mm x 7.1mm Upper | 40mm x 51.8mm x 7.5mm Lower | 1.5"" Crown Race |
| Front Hub | Shimano MT410 | 15mm Boost |
| Rear Hub | Shimano MT400 Boost 148mm |
| Spokes | 2.0 Stainless |
| Tires | F: WTB Ranger Comp 29 x 2.3 | R: WTB Ranger Comp 29 x 2.3 |
| Rim | Rocky Mountain TR30 Tubeless | 32H | Tubeless Compatible - Tape | Valves | Sealant Not Incl |
| Weight NW | 16 KGS |
